Lanco Type Die Head – Sizes & Machine Compatibility

Review Lanco Type Die Head for your component and the required production operation.

Compare the working range with the component

A model intended to carry matched threading chasers for external thread cutting on compatible machines must be assessed against the full job dimensions. Supply machine model, die-head interface, chaser dimensions and the thread required. Separate overall workpiece size from the portion processed during the operation; a single headline capacity does not describe every possible component.

Check the configuration behind the model data

Use the specification table alongside a review of mounting compatibility, chaser seating, setting procedure and operating clearances. Confirm units and the tool or fixture arrangement included in the proposed model. This product is a die-head accessory; confirm its interface with the intended threading machine before ordering. If more than one component size is needed, list the complete range and discuss the required changeovers.

Confirm the selected model in writing

Specify the acceptance requirements for a representative cut thread and fit of the complete head-and-chaser arrangement. Ask IMC to identify the model, working range, included tooling and accessories against your drawing. Include material, batch quantities, power supply and delivery location. Select the available options and add the quantity to the Quote List. The final offer should make the configuration and application clear instead of treating the product designation as the complete technical specification.

Information to send with your enquiry

• Machine model
• Die-head interface
• Chaser dimensions and the thread required

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.
