Automatic Flat Die Thread Rolling Machine – Models & Capacity

Review Automatic Flat Die Thread Rolling Machine for your component and the required production operation.

Compare the working range with the component

A model intended to form threads on suitable bolt blanks using an automatic flat-die rolling configuration must be assessed against the full job dimensions. Supply fastener drawing, blank material and dimensions, thread profile and batch size. Separate overall workpiece size from the portion processed during the operation; a single headline capacity does not describe every possible component.

Check the configuration behind the model data

Use the specification table alongside a review of flat dies, the feeding configuration supplied and size-change arrangements. Confirm units and the tool or fixture arrangement included in the proposed model. Confirm which feeding and handling operations are included in the offered automatic configuration. If more than one component size is needed, list the complete range and discuss the required changeovers.

Confirm the selected model in writing

Specify the acceptance requirements for thread fit, formed profile and handling of accepted and rejected components. Ask IMC to identify the model, working range, included tooling and accessories against your drawing. Include material, batch quantities, power supply and delivery location. Select the available options and add the quantity to the Quote List. The final offer should make the configuration and application clear instead of treating the product designation as the complete technical specification.

Information to send with your enquiry

• Fastener drawing
• Blank material and dimensions
• Thread profile and batch size

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.
